Genset model |
HL150GF |
|
Prime power (KW/KVA) |
150/188 |
|
Standby power (KW/KVA) |
165/206 |
|
Frequency & voltage |
50HZ, 400V |
|
No. of Phase |
3 |
|
Genset type |
Soundproof/silent type |
|
Reference Dimension & Weight |
3500*1100*1800; 2100kgs |
|
DIESEL ENGINE |
|
|
Engine |
CUMMINS brand 6CTAA8.3-G2 |
|
Rated output |
183KW |
|
Rated Speed |
1500RPM |
|
Engine Type |
Vertical in-line, four stroke |
|
No. of cylinder |
6 |
|
Bore*stroke |
114*135mm |
|
Aspiration method |
Turbocharged after air-air cooled |
|
Governor |
Electrical |
|
Starting method |
Electric starting |
|
Cooling method |
Forced water cooled |
|
Displacement |
8.3L |
|
Compression ratio |
16.5:1 |
|
Fuel consumption |
205g/kw.h |
|
Speed stability |
≤5% |
|
Total lubrication system capacity |
24L |
|
Coolant capacity(without radiator) |
12.3L |
|
Starter motor |
DC24V |
|
Alternator |
AC24V |
|
ALTERNATOR |
|
|
Alternator brand & model |
Stamford/China reputed brand |
|
Type |
Brushless & self-excited |
|
No. of phase |
3 |
|
Voltage |
400V |
|
Frequency |
50HZ |
|
Power Factor |
0.8 |
|
Insulation Grade |
H |
|
Protection Grade |
IP22/23 |
|
Altitude |
≤1000m |
